2PC912
Nexans ref. 2PC912
- Verpackung: Cut to length (m)
- Kabeltype: CAT 5E
- Leitungsaufbau: 2 x (2 x 0.25²)
- Mantelfarbe: Schwarz
- Aderkennzeichnung: Red,Yellow,Blue,Black
- Außendurchmesser, nom.: 6,5 mm
- Nettogewicht ca.: 55 kg/km
- Min. Betriebstemperatur: -25 °C
2PK592
Nexans ref. 2PK592
- Verpackung: Cut to length (m)
- Kabeltype: CAT 5E
- Leitungsaufbau: 2 x (2 x 0.50²)
- Mantelfarbe: Schwarz
- Aderkennzeichnung: By Identification tapes - Red,Yellow,Blue
- Außendurchmesser, nom.: 9,7 mm
- Nettogewicht ca.: 120 kg/km
- Min. Betriebstemperatur: -25 °C
2PI232
Nexans ref. 2PI232
- Verpackung: Cut to length (m)
- Kabeltype: CAT 5E
- Leitungsaufbau: 2 x (2 x 0.50²)
- Mantelfarbe: Schwarz
- Aderkennzeichnung: By Identification tapes - Red,Yellow,Blue
- Außendurchmesser, nom.: 9,7 mm
- Nettogewicht ca.: 120 kg/km
- Min. Betriebstemperatur: -40 °C
2PK319
Nexans ref. 2PK319
- Verpackung: Cut to length (m)
- Kabeltype: CAT 5E
- Leitungsaufbau: 4 x 0.25²
- Mantelfarbe: Blau
- Aderkennzeichnung: C
- Außendurchmesser, nom.: 6,7 mm
- Nettogewicht ca.: 65 kg/km
- Min. Betriebstemperatur: -25 °C
2PK699
Nexans ref. 2PK699
- Verpackung: Cut to length (m)
- Kabeltype: CAT 5E
- Leitungsaufbau: 4 x 0.25²
- Mantelfarbe: Blau
- Aderkennzeichnung: C
- Außendurchmesser, nom.: 6,7 mm
- Nettogewicht ca.: 65 kg/km
- Min. Betriebstemperatur: -40 °C
2PK211
Nexans ref. 2PK211
- Verpackung: Cut to length (m)
- Kabeltype: CAT 5E
- Leitungsaufbau: 4 x 0.50²
- Mantelfarbe: Blau
- Aderkennzeichnung: C
- Außendurchmesser, nom.: 8,5 mm
- Nettogewicht ca.: 96 kg/km
- Min. Betriebstemperatur: -25 °C
2PK698
Nexans ref. 2PK698
- Verpackung: Cut to length (m)
- Kabeltype: CAT 5E
- Leitungsaufbau: 4 x 0.50²
- Mantelfarbe: Blau
- Aderkennzeichnung: C
- Außendurchmesser, nom.: 8,5 mm
- Nettogewicht ca.: 96 kg/km
- Min. Betriebstemperatur: -40 °C
Ethenet 4 x AWG 20/19
Nexans ref. 45923010
- Verpackung: Cut to length (m)
- Kabeltype: CAT 5E
- Leitungsaufbau: 4 x AWG 20/19
- Mantelfarbe: Schwarz
- Aderkennzeichnung: D
- Außendurchmesser, nom.: 7,8 mm
- Nettogewicht ca.: 96 kg/km
- Min. Betriebstemperatur: -40 °C
Ethernet 4 x AWG 22/19 (0,34²)
Nexans ref. 45993310
- Verpackung: Cut to length (m)
- Kabeltype: CAT 5E
- Leitungsaufbau: 4 x AWG 22/19 (0,34²)
- Mantelfarbe: Schwarz
- Aderkennzeichnung: C
- Außendurchmesser, nom.: 6,9 mm
- Nettogewicht ca.: 74 kg/km
- Min. Betriebstemperatur: -40 °C
Ethernet 4 x AWG 22/19 (0,34²)
Nexans ref. 45994010
- Verpackung: Cut to length (m)
- Kabeltype: CAT 5E
- Leitungsaufbau: 4 x AWG 22/7 (0,34²)
- Mantelfarbe: Schwarz
- Aderkennzeichnung: C
- Außendurchmesser, nom.: 7,2 mm
- Nettogewicht ca.: 77 kg/km
- Min. Betriebstemperatur: -40 °C
2PM022
Nexans ref. 2PM022
- Verpackung: Cut to length (m)
- Kabeltype: CAT 5E
- Leitungsaufbau: 4 x AWG 22/7 (0,34²)
- Mantelfarbe: Blau
- Aderkennzeichnung: C
- Außendurchmesser, nom.: 6,5 mm
- Nettogewicht ca.: 62 kg/km
- Min. Betriebstemperatur: -25 °C
2PG229
Nexans ref. 2PG229
- Verpackung: Cut to length (m)
- Kabeltype: CAT 5E
- Leitungsaufbau: 4 x AWG 22/7 (0,34²)
- Mantelfarbe: Schwarz
- Aderkennzeichnung: D
- Außendurchmesser, nom.: 6,5 mm
- Nettogewicht ca.: 62 kg/km
- Min. Betriebstemperatur: -25 °C
2PM676
Nexans ref. 2PM676
- Verpackung: Cut to length (m)
- Kabeltype: CAT 5E
- Leitungsaufbau: 4 x AWG 22/7 (0,34²)
- Mantelfarbe: Blau
- Aderkennzeichnung: C
- Außendurchmesser, nom.: 6,5 mm
- Nettogewicht ca.: 62 kg/km
- Min. Betriebstemperatur: -40 °C
2PK847
Nexans ref. 2PK847
- Verpackung: Cut to length (m)
- Kabeltype: CAT 5E
- Leitungsaufbau: 4 x AWG 22/7 (0,34²)
- Mantelfarbe: Schwarz
- Aderkennzeichnung: D
- Außendurchmesser, nom.: 6,5 mm
- Nettogewicht ca.: 62 kg/km
- Min. Betriebstemperatur: -40 °C
2PM577
Nexans ref. 2PM577
- Verpackung: Cut to length (m)
- Kabeltype: CAT 6A
- Leitungsaufbau: 4 x (2 x 0.25²)
- Mantelfarbe: Blau
- Aderkennzeichnung: Red,Yellow,Blue,Black
- Außendurchmesser, nom.: 8,5 mm
- Nettogewicht ca.: 80 kg/km
- Min. Betriebstemperatur: -40 °C
2PM578
Nexans ref. 2PM578
- Verpackung: Cut to length (m)
- Kabeltype: CAT 6A
- Leitungsaufbau: 4 x (2 x 0.50²)
- Mantelfarbe: Blau
- Aderkennzeichnung: Red,Yellow,Blue,Black
- Außendurchmesser, nom.: 11,9 mm
- Nettogewicht ca.: 147 kg/km
- Min. Betriebstemperatur: -40 °C
2PM615
Nexans ref. 2PM615
- Verpackung: Cut to length (m)
- Kabeltype: CAT 7
- Leitungsaufbau: 4 x (2 x 0.25²)
- Mantelfarbe: Blau
- Aderkennzeichnung: Red,Yellow,Blue,Black
- Außendurchmesser, nom.: 8,5 mm
- Nettogewicht ca.: 82 kg/km
- Min. Betriebstemperatur: -40 °C
2PM622
Nexans ref. 2PM622
- Verpackung: Cut to length (m)
- Kabeltype: CAT 7
- Leitungsaufbau: 4 x (2 x AWG 24/7)
- Mantelfarbe: Schwarz
- Aderkennzeichnung: Red,Yellow,Blue,Black
- Außendurchmesser, nom.: 8,1 mm
- Nettogewicht ca.: 71 kg/km
- Min. Betriebstemperatur: -40 °C
2PM697
Nexans ref. 2PM697
- Verpackung: Cut to length (m)
- Kabeltype: CAT 7
- Leitungsaufbau: 4 x (2 x AWG 26/7)
- Mantelfarbe: Schwarz
- Aderkennzeichnung: Red,Yellow,Blue,Black
- Außendurchmesser, nom.: 7,1 mm
- Nettogewicht ca.: 55 kg/km
- Min. Betriebstemperatur: -40 °C
2PM617
Nexans ref. 2PM617
- Verpackung: Cut to length (m)
- Kabeltype: CAT 7A
- Leitungsaufbau: 4 x (2 x 0.25²)
- Mantelfarbe: Schwarz
- Aderkennzeichnung: Red,Yellow,Blue,Black
- Außendurchmesser, nom.: 8,5 mm
- Nettogewicht ca.: 85 kg/km
- Min. Betriebstemperatur: -40 °C
Beschreibung
Beschreibung
Normen
-
InternationalEN 45545-2 (HL3)
Anwendung
Nexans develops halogen-free communication cables for higher transmission performances to address emerging applications.
FLAMEX® communication cables are conform to EN 45545-2, easy to pool, quick to connect and compatible with standard connectors, and designed to improve the protection against electrical disturbances, electromagnetic noises. Nexans experience in the design of shielding technology enables us to propose all constructions with high EMC protection. All these features make FLAMEX® cables the best candidate for new built and retrofit works.
Eigenschaften
Eigenschaften
Konstruktionsmerkmale
Konstruktionsmerkmale
Anwendungsmerkmale
Anwendungsmerkmale
Ressourcen
Ressourcen
Verkauf & Lieferung Informationen
A: Color coding for pairs
N°1: white + blue
N°2: white + orange
N°3: white + green
N°4: white + brown
B: Color coding for pairs: N°1: white + blue N°2: yellow + orange
C: Color coding for quads: N°1: white + blue N°2: yellow + orange
D: Color coding for quads: N°1: white + yellow N°2: red + black
